AL-18-CY Natural Gas/Propane Torch

CONSTRUCTION:  Stainless steel, 18 gauge (.043 thickness) outer cylinder with Plasma Cut design, brass base, cast brass pipe adapter & internal parts. Stainless Steel interior perforated flame screen.

Optional brass or copper outer cylinder available

NATURAL GAS USAGE (AL-18-CYNG):  22,500 BTU/Hour normal inlet pressure 7″ water column

PROPANE GAS USAGE (AL-18-CYP):  17,000 BTU/Hour normal inlet pressure 11″ water column

INSTALLATION:  1” cast brass adapter has standard female NPT pipe threads for connection
to 1” steel pipe (supplied by others). Optional 3/4″ adapter available – see spec sheet for details

VALVE:  1” brass shut-off valve required (supplied by others)

IGNITION:  Manual ignition with extended lighter

FINISH:  Unfinished

Black Texture (-BLT)
White Texture (-WTX)
Bronze Texture (-BRT)
Rust (-RST)
Rubbed Verde (-RBV)
Hunter Texture (-HTX)
Weathered Brown (-WBR)
Stucco (-STU)
Weathered Iron (-WIR)
Chrome Powder (-CPR)
Acid Rust (-BAR/CAR)
Brass & Copper Only
Acid Verde (-BAV/CAV)
Brass & Copper Only
Black Acid Treatment (-BAT)
Brass & Copper Only
Catalog No. Description Lamp
AL-18-CY001NGSS Stainless Steel, Sandstone Design, Natural Gas Fed Torch NA
AL-18-CY001PSS Stainless Steel, Sandstone Design, Propane Fed Torch NA
AL-18-CY003NGSS Stainless Steel, Circles Design, Natural Gas Fed Torch NA
AL-18-CY003PSS Stainless Steel, Circles Design, Propane Fed Torch NA
