SL-16P-S

CONSTRUCTION:  316 stainless steel or brass cylinder, pendant and canopy

LENS:  Translucent acrylic snoot with 3 avaialable finishes;
S1 – Clear
S2 – 100% Frosted
S3 – Frosted sides with clear top and bottom

CANOPY GASKET:  Black newsponge closed cell .190″ thickness

LAMP SUPPLIED:  None, uses MR16 lamps

LAMP OPTIONS:  We recommend 4w ARROW LED (-LED) 50,000 average rating

SOCKET:  High temperature ceramic GU5.3 bi-pin with 250°C silicone lead wires

WIRING:  Black and 2 White 250°C silicone lead wires

CONNECTION:  FA-05 Quick Connector (not supplied) from fixture to main cable
(12/2, 10/2 or 8/2 only)

MOUNTING:  Canopy included with 2 stainless steel or brass #2 Phillips, flat head, wood screws  Optional FA-24-LG canopy to cover 4O box with mounting hardware

FINISH:  Stainless Steel-Machined stainless steel only
Brass-Unfinished brass. Optional finishes available

Black Texture (-BLT)
White Texture (-WTX)
Bronze Texture (-BRT)
Rust (-RST)
Antique Verde (-ATV)
Rubbed Verde (-RBV)
Hunter Texture (-HTX)
Weathered Brown (-WBR)
Stucco (-STU)
Weathered Iron (-WIR)
Camel Tone (-CAM)
Chrome Powder (-CPR)
Acid Rust (-BAR/CAR)
Brass & Copper Only
Acid Verde (-BAV/CAV)
Brass & Copper Only
Black Acid Treatment (-BAT)
Brass & Copper Only
SKU: SL-16P-S Categories: , Tags: ,
Catalog No. Description
SL16-P-MR16-S1-NL-SS NO LAMP, STAINLESS PENDANT, CLEAR SNOOT
SL16-P-MR16-S1-LED-SS 4W LED, STAINLESS PENDANT, CLEAR SNOOT
SL16-P-MR16-S1-NL-BRS NO LAMP, BRASS PENDANT, CLEAR SNOOT
SL16-P-MR16-S1-LED-BRS 4W LED, BRASS PENDANT, CLEAR SNOOT
SL16-P-MR16-S2-NL-SS NO LAMP, STAINLESS PENDANT, FROSTED SNOOT
SL16-P-MR16-S2-LED-SS 4W LED, STAINLESS PENDANT, FROSTED SNOOT
SL16-P-MR16-S2-NL-BRS NO LAMP, BRASS PENDANT, FROSTED SNOOT
SL16-P-MR16-S2-LED-BRS 4W LED, BRASS PENDANT, FROSTED SNOOT
SL16-P-MR16-S3-NL-SS NO LAMP, STAINLESS PENDANT, FROST/CLEAR SNOOT
SL16-P-MR16-S3-LED-SS 4W LED, STAINLESS PENDANT, FROST/CLEAR SNOOT
SL16-P-MR16-S3-NL-BRS NO LAMP, BRASS PENDANT, FROST/CLEAR SNOOT
SL16-P-MR16-S3-LED-BRS 4W LED, BRASS PENDANT, FROST/CLEAR SNOOT
 Extended snoots available. See specification sheet for details
