PGL-03

CONSTRUCTION: Cast aluminum or brass Bullet with cast aluminum or brass adjustable swivel; matching extruded aluminum or brass stanchion

LENS: Sandblasted wide spread tempered flat glass

GASKET: Black neosponge closed cell; .190″ thickness

LAMP SUPPLIED: 35w MR16 VWFL(FMW); 5000 hours rating (50w max.)

LAMP OPTIONS: We recommend ARROW 4w LED (-LED) or 6w LED (-LED6W); 50,000 hour
or ARROW SAVER 4w LED (-LAS); 40,000 hour

SOCKET: High temp ceramic GU5.3 bi-pin with 250°C silicone lead wires

WIRING: Black 3 foot 18/2 zip cord (12v only)
For 25 foot 16/2 fixture lead wire add -25F to catalog number.

CONNECTION: FA-05 Quick Connector (not supplied) from fixture to main cable (12/2, 10/2 or 8/2 only)

FINISH: Aluminum – Black texture polyester powder coat. Optional finishes available.
Brass – Unfinished. Optional finishes available.

Black Texture (-BLT)
White Texture (-WTX)
Bronze Texture (-BRT)
Rust (-RST)
Antique Verde (-ATV)
Rubbed Verde (-RBV)
Hunter Texture (-HTX)
Weathered Brown (-WBR)
Stucco (-STU)
Weathered Iron (-WIR)
Camel Tone (-CAM)
Chrome Powder (-CPR)
Acid Rust (-BAR/CAR)
Brass & Copper Only
Acid Verde (-BAV/CAV)
Brass & Copper Only
Black Acid Treatment (-BAT)
Brass & Copper Only
SKU: PGL-03 Category: Tags: , ,
Catalog No. Description Lamp
PGL-03-BLT Aluminum Putting Green Light 35w MR16 VWFL(FMW)
PGL-03-BRS Brass Putting Green Light 35w MR16 VWFL(FMW)
