| Catalog No. | Description | Lamp |
|---|---|---|
| RXA-02-COP | Copper 3.5″ China Hat, with Adjustable Hub | 20w T4 Halogen |
| RXA-02-F-COP | Copper 3.5″ China Hat, Finial, with Adjustable Hub | 20w T4 Halogen |
| RXA-02-SS | 316 Stainless Steel 3.5″ China Hat, with Adjustable Hub | 20w T4 Halogen |
| RXA-02-F-SS | 316 Stainless Steel 3.5″ China Hat, Finial, with Adjustable Hub | 20w T4 Halogen |
| RXA-02-BLT | Aluminum 3.5″ China Hat, with Adjustable Hub | 20w T4 Halogen |
| RXA-02-F-BLT | Aluminum Steel 3.5″ China Hat, Finial, with Adjustable Hub | 20w T4 Halogen |
| RXA-02-2T-COP | Copper 3.5″ China Hat, 2 Tiers w/ Finial & Adjustable Hub | 20w T4 Halogen |
| RXA-02-2T-BLT | Aluminum 3.5″ China Hat, 2 Tiers w/ Finial & Adjustable Hub | 20w T4 Halogen |
RXA-02
CONSTRUCTION: Spun copper, aluminum or 316 stainless steel China Hat with matching extruded stanchion; Copper model features cast brass adjustable hub; Stainless model has matching cast 316 stainless steel hub; Aluminum model has aluminum hub
LAMP OPTIONS: LED & legacy lamp options see specification sheet
SOCKET: Single contact bayonet, brass nickel plated lamp socket screw shell (Ba15s)
MOUNTING: FA-03 black 9″ ABS stake, tapped 1/2″ NPS
FINISH: Copper – Unfinished.
Stainless Steel – Brushed.
Aluminum-Black texture polyester powder coat. Optional finishes available.
Black Texture (-BLT)
White Texture (-WTX)
Bronze Texture (-BRT)
Rust (-RST)
Rubbed Verde (-RBV)
Hunter Texture (-HTX)
Weathered Brown (-WBR)
Stucco (-STU)
Weathered Iron (-WIR)
Chrome Powder (-CPR)
Acid Rust (-BAR/CAR)
Brass & Copper Only
Brass & Copper Only
Acid Verde (-BAV/CAV)
Brass & Copper Only
Brass & Copper Only
Black Acid Treatment (-BAT)
Brass & Copper Only
Brass & Copper Only
