| Catalog No. | Est. Ship Weight | Carton Dimensions |
|---|---|---|
| Aluminum | 2 lbs. | 18" x 3" x 3" |
| Copper | 2 lbs. | 18" x 3" x 3" |
RXA02
Product Specifications
Construction
Spun Aluminum or copper small China hat with matching stem and hub
Copper fixture supplied with brass hub
Copper fixture supplied with brass hub
Voltage
12 Volt / 120 Volt
LED / Lamp
12 Volt: 3w Omni Super Saver LED (L12) Single Contact [Standard]
120 Volt: 3w Omni 3 Super Saver LED (L160) Bi-Pin
120 Volt: 3w Omni 3 Super Saver LED (L160) Bi-Pin
CCT
3000K
Lumens
12 Volt: 300LM
120 Volt: 440lm
120 Volt: 440lm
Socket
12 Volt: Single Contact / Bi-Pin
120 Volt: Bi-Pin
120 Volt: Bi-Pin
Lifetime Rating
50,000 Hours
Mounting
FA03 Black ABS Stake
Finish
Copper: Unfinished
Optional powder coat and acid finishes available
Optional powder coat and acid finishes available
DOWNLOADS
FA03
Black ABS Stake
Available Finishes
Select any finish below to view a larger preview. Finish availability may vary by fixture material. Premium powder coat and acid treatment finishes may carry additional charges.
STANDARD FINISHES
PREMIUM FINISHES
ACID FINISHES
Acid Finish Disclaimer:
Acid-treated finishes are created through a natural chemical reaction and may vary in color, tone, pattern, and overall appearance from fixture to fixture. Variations are inherent to the finishing process and are not considered defects. Website images and finish samples are intended as a general representation only.
