CONSTRUCTION:  4.5″ diameter aluminum, brass, or black ABS bollard with aluminum or brass top (ABS has black aluminum top)

LENS:  White high-impact acrylic

LIGHT SOURCE:  2x 4w 350 lumen LED flat panels, warm white 3000K; optional cool white 5200K 380 lumen available (modify part number to “LEDP52”)

LIFETIME RATING:  50,000 hours

12v INTERNAL DRIVER:  2x 5w 12vDC 350mA output, 12vAC input

120v INTERNAL DRIVER:  2x 6w 12vDC 350mA output, 100-265vAC input

SOCKET:  None – LED is hard wired inside fixture

MOUNTING:  Ground Mount – 4 RP-42 black ABS stabilizing fins
Deck Mount – U-bracket with 4 mounting screws (Add -DM to part number)

FINISH:  Aluminum – Black texture polyester powder coat. Optional finishes available.
Brass – Unfinished brass. Optional finishes available.
ABS – Black or Rubbed Verde.

Black Texture (-BLT)
White Texture (-WTX)
Bronze Texture (-BRT)
Rust (-RST)
Rubbed Verde (-RBV)
Hunter Texture (-HTX)
Weathered Brown (-WBR)
Stucco (-STU)
Weathered Iron (-WIR)
Chrome Powder (-CPR)
Acid Rust (-BAR/CAR)
Brass & Copper Only
Acid Verde (-BAV/CAV)
Brass & Copper Only
Black Acid Treatment (-BAT)
Brass & Copper Only


Catalog No. Description Lamp
AL-08-LG-LEDP4W12-BLT 12v Black ABS 4.50″ Bollard 2 X 4W LED Panel
AL-08-LG-LEDP4W120-BLT 120v Black aluminum 4.50″ Bollard 2 X 4W LED Panel
AL-08-LG-AL-LEDP4W12-BLT 12v Aluminum 4.50″ Bollard 2 X 4W LED Panel
AL-08-LG-AL-LEDP4W120-BLT 120v Aluminum 4.50″ Bollard 2 X 4W LED Panel
AL-08-LG-AL-LEDP4W12-BRS 12v Brass 4.50″ Bollard 2 X 4W LED Panel
AL-08-LG-AL-LEDP4W120-BRS 120v Brass 4.50″ Bollard 2 X 4W LED Panel
