LFL-01-LEDP12 / LEDP24

CONSTRUCTION:  Extruded aluminum floodlight with cast aluminum adjustable swivel. Heavy-duty stamped aluminum Hood Extension available (add -HE to part number)

LENS:  High impact clear acrylic

REFLECTOR:  Highly polished specular aluminum

LIGHT SOURCE: Each LED Panel is:12v, 12w, 1080 lumens integrated LED flat panel, warm white 3000K or 12v, 12w, 1160 lumens integrated LED flat panel, coolwhite 5200K (add-52 to part number)

LIFETIME RATING:  50,000 hours

SOCKET:  None

12V INTERNAL DRIVER:  12w output, 12v AC input.  Voltage range of 9 to 18 volts with optimum operating range of 10 to 15 volts for consistent performance and brightness.
For use with magnetic transformers only.

120V INTERNAL DRIVER:  12w output, 120v 20/60Hz input.
240v/277v  internal drivers also available

WIRING 12v:  Black 3 foot 18/2 zip cord from base of fixture (12v only)
For 25 foot 16/2 fixture lead wire add -25F to catalog number.

WIRING 120v: Standard 120v Black, White and Ground 9″ lead wires

MOUNTING 12v: FA-03LG black 9″ ABS stake, tapped 1/2″ NPS

MOUNTING 120v: None supplied. See Mounting Accessories below for options

FINISH:  Black texture polyester powder coat. Optional finishes available

Black Texture (-BLT)
White Texture (-WTX)
Bronze Texture (-BRT)
Rust (-RST)
Antique Verde (-ATV)
Rubbed Verde (-RBV)
Hunter Texture (-HTX)
Weathered Brown (-WBR)
Stucco (-STU)
Weathered Iron (-WIR)
Camel Tone (-CAM)
Chrome Powder (-CPR)
Acid Rust (-BAR/CAR)
Brass & Copper Only
Acid Verde (-BAV/CAV)
Brass & Copper Only
Black Acid Treatment (-BAT)
Brass & Copper Only
SKU: LFL-01-LEDP12 / LEDP24 Categories: , Tags: , , ,
Catalog No. Description Lamp
LFL-01-LEDP1212VBLT Aluminum Floodlight 12w LED Panel
LFL-01-HELEDP1212VBLT Aluminum Floodlight Hood Extension 12w LED Panel
LFL-01-LEDP12120VBLT 120v Aluminum Floodlight Hood Extension 12w LED Panel
LFL-01-HELEDP12120VBLT 120v Aluminum Floodlight Hood Extension 12w LED Panel
LFL-01-LEDP12277VBLT 277v Aluminum Floodlight 12w LED Panel
LFL-01-HELEDP12277VBLT 277v Aluminum Floodlight Hood Extension 12w LED Panel
LFL-01-LEDP2412VBLT Aluminum Floodlight 2x 12w LED Panels
LFL-01-HELEDP2412VBLT Aluminum Floodlight Hood Extension 2x 12w LED Panels
LFL-01-LEDP24120VBLT 120v Aluminum Floodlight Hood Extension 2x 12w LED Panels
LFL-01-HELEDP24120VBLT 120v Aluminum Floodlight Hood Extension 2x 12w LED Panels
LFL-01-LEDP24277VBLT 277v Aluminum Floodlight 2x 12w LED Panels
LFL-01-HELEDP24277VBLT 277v Aluminum Floodlight Hood Extension 2x 12w LED Panels
