DL-40-LEDP

CONSTRUCTION:  Die cast aluminum or die cast brass floodlight with heavy duty adjustable die cast aluminum or die cast brass swivel

LENS:  High impact clear tempered flat glass

GASKET: High temperature red silicone

REFLECTOR:  Highly polished diamond embossed aluminum

LIGHT OPTIONS:  LED & legacy lamp options see specification sheet

12V INTERNAL DRIVER:  10w 12vDC 700mA output, 12vAC input

120V INTERNAL DRIVER:  10w 12vDC 700mA output, 100-265vAC input.  240v/277v internal drivers also available

MOUNTING:  Aluminum: FA-03 black 9″ ABS stake, tapped 1/2″NPS
Brass: FA-03-LG black 9″ oversize ABS stake, tapped 1/2″NPS

FINISH: Aluminum – Black texture polyester powder coat. Optional finishes available
Brass – Unfinished brass. Optional finishes available

Black Texture (-BLT)
White Texture (-WTX)
Bronze Texture (-BRT)
Rust (-RST)
Antique Verde (-ATV)
Rubbed Verde (-RBV)
Hunter Texture (-HTX)
Weathered Brown (-WBR)
Stucco (-STU)
Weathered Iron (-WIR)
Camel Tone (-CAM)
Chrome Powder (-CPR)
Acid Rust (-BAR/CAR)
Brass & Copper Only
Acid Verde (-BAV/CAV)
Brass & Copper Only
Black Acid Treatment (-BAT)
Brass & Copper Only
SKU: DL-40-LEDP Category: Tags: ,
Catalog No. Description Lamp
DL-40-LEDP-BLT Cast Aluminum Floodlight 8w LED Panel
DL-40-LEDP-BRS Cast Brass Floodlight 8w LED Panel
