DL-40-LEDP

CONSTRUCTION: Die cast aluminum or die cast brass floodlight with heavy duty adjustable die cast aluminum or die cast brass swivel

LENS: High impact clear tempered flat glass

GASKET: High temperature red silicone

REFLECTOR: Highly polished diamond embossed aluminum

LIGHT OPTIONS: LED & legacy lamp options see specification sheet

12V INTERNAL DRIVER: 8w output, 12v AC input.  Voltage range of 9 to 18 volts with optimum operating range of 10 to 15 volts for consistent performance and brightness.

For use with magnetic transformers only.

120V INTERNAL DRIVER: 8w output, 120v 20/60Hz input.
240v/277v  internal drivers also available

MOUNTING: Aluminum: FA-03 black 9″ ABS stake, tapped 1/2″NPS
Brass: FA-03-LG black 9″ oversize ABS stake, tapped 1/2″NPS

FINISH: Aluminum – Black texture polyester powder coat. Optional finishes available
Brass – Unfinished brass. Optional finishes available

Black Texture (-BLT)
White Texture (-WTX)
Bronze Texture (-BRT)
Rust (-RST)
Antique Verde (-ATV)
Rubbed Verde (-RBV)
Hunter Texture (-HTX)
Weathered Brown (-WBR)
Stucco (-STU)
Weathered Iron (-WIR)
Camel Tone (-CAM)
Chrome Powder (-CPR)
Acid Rust (-BAR/CAR)
Brass & Copper Only
Acid Verde (-BAV/CAV)
Brass & Copper Only
Black Acid Treatment (-BAT)
Brass & Copper Only
SKU: DL-40-LEDP Category: Tags: ,
Catalog No. Description Lamp
DL-40-LEDP-BLT Cast Aluminum Floodlight 8w LED Panel
DL-40-LEDP-BRS Cast Brass Floodlight 8w LED Panel
