| Catalog No. | Description | Lamp |
|---|---|---|
| LFL-01-LEDP812VBLT | Aluminum Floodlight | 8w, 3000K 12v LED Panel |
| LFL-01-HELEDP812VBLT | Aluminum Floodlight, hood extension | 8w, 3000K 12v LED Panel |
| LFL-01-LEDP8120VBLT120v Aluminum Floodlight | Aluminum Floodlight | 8w, 3000K 120v LED Panel |
| LFL-01-HELEDP8120VBLT | Aluminum Floodlight, hood extension | 8w, 3000K 120v LED Panel |
| LFL-01-LEDP8240VBLT | Aluminum Floodlight | 8w, 3000K 240v LED Panel |
| LFL-01-HELEDP8240VBLT | Aluminum Floodlight, hood extension | 8w, 3000K 240v LED Panel |
| LFL-01-LEDP8277VBLT | Aluminum Floodlight | 8w, 3000K 277v LED Panel |
| LFL-01-HELEDP8277VBLT | Aluminum Floodlight, hood extension | 8w, 3000K 277v LED Panel |
LFL-01
CONSTRUCTION: Extruded aluminum floodlight with cast aluminum adjustable swivel.
Heavy-duty stamped aluminum Hood Extension available (add -HE to part number)
LENS: High impact clear acrylic
REFLECTOR: Highly polished specular aluminum
LIGHT SOURCE: 12v, 8w integrated LED flat panel, warm white 3000K
LIFETIME RATING: 50,000 hours
SOCKET: None
12V INTERNAL DRIVER: 8w output, 12v AC input. Voltage range of 9 to 18 volts with optimum operating range of 10 to 15 volts for consistent performance and brightness.
For use with magnetic transformers only.
120V INTERNAL DRIVER: 8w output, 120v 20/60Hz input.
MOUNTING 12v: FA-03 black 9″ ABS stake, tapped 1/2″ NPS
MOUNTING 120v: None supplied. See Mounting Accessories below for options
FINISH: Black texture polyester powder coat. Optional finishes available.
Black Texture (-BLT)
White Texture (-WTX)
Bronze Texture (-BRT)
Rust (-RST)
Rubbed Verde (-RBV)
Hunter Texture (-HTX)
Weathered Brown (-WBR)
Stucco (-STU)
Weathered Iron (-WIR)
Chrome Powder (-CPR)
