DL45

CONSTRUCTION:  Cast aluminum or cast brass integrated heat sink base; matching cast adjustable swivel with 240° rotation;
extruded aluminum, brass or copper housing (copper housing has brass base)

LENS:  High impact clear tempered convex glass

O-RING:  2x high temperature red silicone

LIGHT SOURCE:  50,000 hour Integrated 2700K 900 lumen 15w LED module (equivalent to 100w halogen) with 6 high power Cree XPE LEDs

OPTICS:  Interchangeable 15° spot, 40° flood, 60° wide flood and 160˚ widest flood (no optics)

DRIVER:
12v Driver:  Integrated on-board, no external driver required.
12v AC/DC input
120v/277v* Driver: See specification sheet
*Must use FA-26 mounting post or junction box

MOUNTING:
Aluminum model:  FA-03 black 9″ ABS stake, tapped 1/2″ NPS
Brass & Copper models:  FA-03-LG large black 9″ ABS stake, tapped 1/2″ NPS

FINISH:  Aluminum – Black texture polyester powder coat. Optional finishes available.
Brass & Copper – Unfinished. Optional finishes available.

Black Texture (-BLT)
White Texture (-WTX)
Bronze Texture (-BRT)
Rust (-RST)
Rubbed Verde (-RBV)
Hunter Texture (-HTX)
Weathered Brown (-WBR)
Stucco (-STU)
Weathered Iron (-WIR)
Chrome Powder (-CPR)
Acid Rust (-BAR/CAR)
Brass & Copper Only
Acid Verde (-BAV/CAV)
Brass & Copper Only
Black Acid Treatment (-BAT)
Brass & Copper Only

Documentation

Catalog No. Description Lamp
DL45LEDM1515BLT Aluminum Bullet, 15° Optics 15w LED Module, 15° Spot
DL45LEDM1540BLT Aluminum Bullet, 40° Optics 15w LED Module, 40° Flood
DL45LEDM1560BLT Aluminum Bullet, 60° Optics 15w LED Module, 60° Wide Flood
DL45LEDM15WFBLT Aluminum Bullet, No Optics 15w LED Module, 160° Widest Flood
DL45LEDM1515BRS Brass Bullet, 15° Optics 15w LED Module, 15° Spot
DL45LEDM1540BRS Brass Bullet, 40° Optics 15w LED Module, 40° Flood
DL45LEDM1560BRS Brass Bullet, 60° Optics 15w LED Module, 60° Wide Flood
DL45LEDM15WFBRS Brass Bullet, No Optics 15w LED Module, 160° Widest Flood
DL45LEDM1515COP Copper Bullet, 15° Optics 15w LED Module, 15° Spot
DL45LEDM1540COP Copper Bullet, 40° Optics 15w LED Module, 40° Flood
DL45LEDM1560COP Copper Bullet, 60° Optics 15w LED Module, 60° Wide Flood
DL45LEDM15WFCOP Copper Bullet, No Optics 15w LED Module, 160° Widest Flood
