| Catalog No. | Description | Lamp |
|---|---|---|
| DL-22-BLT | Cast aluminum Bullet | 20w MR16 FL(BAB) |
| DL-22-BRS | Cast brass Bullet | 20w MR16 FL(BAB) |
| DL-22-SS | Cast Stainless Steel Bullet | 20w MR16 FL(BAB) |
| DL-22-XEC-BLT | Cast aluminum Bullet, X-long collar | 20w MR16 FL(BAB) |
| DL-22-XEC-BRS | Cast brass Bullet, X-long collar | 20w MR16 FL(BAB) |
DL-22
CONSTRUCTION: Cast aluminum, brass or 316 Stainless Steel Bullet; matching heavy duty cast aluminum, brass or 316 Stainless Steel adjustable swivel
LENS: High impact clear tempered convex glass
O-RING: High temperature red silicone
LAMP OPTIONS: LED & legacy lamp options see specification sheet
SOCKET: High temperature ceramic GU5.3 bi-pin with 250°C silicone lead wires
MOUNTING: FA-03 black 9″ ABS stake threaded 1/2″ NPS
FINISH: Aluminum-Black texture polyester powder coat. Optional finishes available.
Brass-Unfinished brass. Optional finishes available. Stainless Steel – machined finish.
Black Texture (-BLT)
White Texture (-WTX)
Bronze Texture (-BRT)
Rust (-RST)
Rubbed Verde (-RBV)
Hunter Texture (-HTX)
Weathered Brown (-WBR)
Stucco (-STU)
Weathered Iron (-WIR)
Chrome Powder (-CPR)
Acid Rust (-BAR/CAR)
Brass & Copper Only
Brass & Copper Only
Acid Verde (-BAV/CAV)
Brass & Copper Only
Brass & Copper Only
Black Acid Treatment (-BAT)
Brass & Copper Only
Brass & Copper Only
