| Catalog No. | Description | Lamp |
|---|---|---|
| AL08MDDMS2L24BLT | 12v 2.5″ dia. X 18″ Medium Aluminum Bollard w/ frosted acrylic accent, deck mount, FA03LG stake mount, Black Texture finish | 3w MR16 SS LED |
| AL08SMDMS2L24BRS | 12v 2.5″ dia. X 18″ Medium Brass Bollard w/ frosted acrylic accent, deck mount, FA03LG stake mount | 3w MR16 SS LED |
| AL08SMDMS2L24COP | 12v 2.5″ dia. X 18″ Medium Copper Bollard w/ frosted acrylic accent, deck mount, FA03LG stake mount | 3w MR16 SS LED |
| AL08MDDMS2L108BLT | 12v 2.5″ dia. X 18″ Medium Aluminum Bollard w/ frosted acrylic accent, deck mount, FA03LG stake mount, Black Texture finish | 3w MR16 SS LED |
| AL08MDDMS2L108BRS | 12v 2.5″ dia. X 18″ Medium Brass Bollard w/ frosted acrylic accent, deck mount, FA03LG stake mount | 3w MR16 SS LED |
| AL08MDDMS2L108COP | 120v 2.5″ dia. X 18″ Medium Copper Bollard w/ frosted acrylic accent, deck mount, FA03LG stake mount | 3w MR16 SS LED |
| AL08SMS2L74BRS | 120v 2.5″ dia. X 18″ Medium Brass Bollard w/ frosted acrylic accent, angle cut, 4 mounting fins (included) | 3w MR16 SS LED |
| AL08SMS2L74COP | 120v 2.5″ dia. X 18″ Medium Copper Bollard w/ frosted acrylic accent, angle cut, 4 mounting fins (included) | 3w MR16 SS LED |
AL08MDS2
CONSTRUCTION: 2.5″ dia. X 18″ Medium Bollard w/ frosted acrylic accent, deck mount, FA03LG mounting stake (included)
LENS: Frosted, high impact acrylic accent (S2)
Color Glass Lenses Available (see brochure for more information)
LED: 3w MR16 SS LED 36° (L24) 3000K, 50,000 hrs, 270 Lumen (12v)
LED OPTION: 3w MR16 SS LED 36° (L24) 3000K, 50,000 hrs, 270 Lumen (120v)
LIFETIME RATING: 50,000 hours
SOCKET: High temperature ceramic GU5.3 Bi-Pin with 250°C silicone lead wires
WIRING: Black 3ft 18/2 zip cord from base of fixture. For 25ft 16/2 fixture lead wire, add (-25F) to part number
CONNECTION: FA05 Quick Connect (not supplied) from fixture to main cable
MOUNTING: Deck Mount (-DM) FA03LG large black ABS 9″ stake, taped 1/2″ NPS
FINISH: Aluminum – Black Texture Finish (BLT) (Powder coat options available)
Brass – Unfinished (Acid & Premium finished available)
Copper – Unfinished (Acid & Premium finished available)
(powder coat and acid finishes over Brass, and Copper are considered custom and non-returnable)
Black Texture (-BLT)
White Texture (-WTX)
Bronze Texture (-BRT)
Rust (-RST)
Rubbed Verde (-RBV)
Hunter Texture (-HTX)
Weathered Brown (-WBR)
Stucco (-STU)
Weathered Iron (-WIR)
Chrome Powder (-CPR)
Acid Rust (-BAR/CAR)
Brass & Copper Only
Brass & Copper Only
Acid Verde (-BAV/CAV)
Brass & Copper Only
Brass & Copper Only
Black Acid Treatment (-BAT)
Brass & Copper Only
Brass & Copper Only
