PL-03-DCLEDP

CONSTRUCTION: Die Cast aluminum or Die Cast brass Shell Hat; matching extruded aluminum or
brass stanchion

LIGHT SOURCE: 12v, 4w, 300 lumen integrated round LED flat panel, warm white 3000K;
optional cool white 5200K 320 lumen available (modify part number to LEDP52)

LIFETIME RATING: 50,000 Hours

12v EXTERNAL DRIVER: 4w 350mA output, 12v AC input. Voltage range of 9 to 18 volts with optimum operating range of 10 to 15 volts for consistent performance and brightness. For use with magnetic transformers only.

SOCKET: None- LED is hard wired inside fixture

LENS: Clear acrylic (standard) Optional sand blast (-SB) or White (-WHT) available

MOUNTING: FA-03 black 9″ ABS stake, tapped 1/2″ NPS

FINISH: Aluminum – Black texture polyester powder coat. Optional finishes available
Brass – Unfinished brass. Optional finishes available

NOTE: Optional 120v to 277v drivers available. Must use FA-26 mounting post or junction box
