DL-07-DC

CONSTRUCTION:  Cast aluminum or brass Shell flood; matching extruded stanchion

LENS:  High impact clear acrylic

LAMP OPTIONS:  LED & legacy lamp options see specification sheet

SOCKET:  Single contact bayonet, brass nickel plated lamp socket screw shell (Ba15s); double contact bayonet base (Ba15d) for 120v, both with 200°C silicone lead wires

MOUNTING:  FA-03 black 9″ ABS stake threaded 1/2″ NPS

FINISH:  Aluminum-Black texture polyester powder coat. Optional finishes available.
Brass-Unfinished brass. Optional finishes available.

Black Texture (-BLT)

White Texture (-WTX)

Bronze Texture (-BRT)

Rust (-RST)

Rubbed Verde (-RBV)

Hunter Texture (-HTX)

Weathered Brown (-WBR)

Stucco (-STU)

Weathered Iron (-WIR)

Chrome Powder (-CPR)

Acid Rust (-BAR/CAR)
Brass & Copper Only

Acid Verde (-BAV/CAV)
Brass & Copper Only

Black Acid Treatment (-BAT)
Brass & Copper Only
