| Catalog No. | Description | Lamp |
|---|---|---|
| AL-09-LEDP | Brass Lantern on Black ABS Stanchion | 4w LED Panel |
| AL-09-LEDP | Black Powder Coat Brass Lantern on Black ABS Stanchion | 4w LED Panel |
| AL-09-LEDP-BRS | Brass Lantern on Brass Stanchion | 4w LED Panel |
| AL-09-ALUM-LEDP-BLT | Black Powder Coat Brass Lantern on Black Alum. Stanchion | 4w LED Panel |
AL-09-LEDP
CONSTRUCTION: Formed solid brass lantern; black ABS, extruded brass or extruded aluminum stanchion
LIGHT SOURCE: 4w 300 lumen integrated round LED flat panel, warm white 3000K; optional cool white 5200K 320 lumen available (modify part number to “LEDP52”)
LIFETIME RATING: 50,000 hours
12V INTERNAL DRIVER: 5w 12vDC 350mA output, 12vAC input
SOCKET: None – LED is hard wired inside fixture
MOUNTING: FA-03 black 9″ ABS stake, tapped 1/2″ NPS
FINISH: Aluminum-Black texture polyester powder coat. Optional finishes available.
Brass-Unfinished brass. Optional finishes available.
NOTE: 120v – 277v options available with remote LED driver. Must use FA-26 mounting post or FA-JBOX junction box to house remote driver.
Black Texture (-BLT)
White Texture (-WTX)
Bronze Texture (-BRT)
Rust (-RST)
Rubbed Verde (-RBV)
Hunter Texture (-HTX)
Weathered Brown (-WBR)
Stucco (-STU)
Weathered Iron (-WIR)
Chrome Powder (-CPR)
Acid Rust (-BAR/CAR)
Brass & Copper Only
Brass & Copper Only
Acid Verde (-BAV/CAV)
Brass & Copper Only
Brass & Copper Only
Black Acid Treatment (-BAT)
Brass & Copper Only
Brass & Copper Only
